Key Performance Features

• EmS Technology: Fully electromechanical operation eliminates the need for compressed air or hydraulic oil, ensuring a clean, quiet, and low-maintenance environment.
• Closed-Loop Angle Control: Features real-time, automatic adjustment of the gyratory angle during compaction to compensate for frame compliance and ensure total accuracy.
• Integrated Shear Measurement: Built-in sensors provide real-time direct shear and torque resistance data, essential for evaluating the workability and stability of advanced mixtures.
• Zero-Angle Finishing: Automatically flattens the specimen at a 0° angle at the end of the test to ensure perfectly parallel faces for subsequent mechanical testing.
• Smart Control & Software: Managed via a 7″ color touchscreen or dedicated PC software for complex data analysis, including automatic compaction energy calculations.

Technical Specifications

• Standard Compliance: Exceeds requirements for AASHTO T312, ASTM D6925, and EN 12697-31.
• Gyratory Angle: User-defined and motorized from 0° to 3° with a resolution of ±0.005°.
• Consolidation Pressure: High-performance motor delivers up to 1000 kPa (for 150 mm dia. samples).
• Rotation Speed: Adjustable from 5 to 60 rpm (standard) up to 120 rpm (on request).
• Measurement Precision: * Height: Better than 0.1 mm resolution.
• Load: Direct measurement via high-precision coaxial load cell.
• Integrated Extruder: Includes a motorized electromechanical extruder and a motorized mold-lifting system for maximum productivity.
• Safety & Connectivity: Transparent sliding door with safety interlock; LAN/Ethernet and USB ports for remote diagnostics and data export.
