Key Performance Features

• Electromechanical Drive: Powered by a high-torque brushless motor and precision ball screw, providing silent operation and maintenance-free longevity.
• Automatic Test Execution: A true “push-button” system that manages approach speed, zeroing, and test speed according to pre-set international standards.
• High Frame Stiffness: Engineered to minimize frame deformation under load, ensuring that all measured displacement originates from the specimen itself.
• Interchangeable Accessories: Designed for rapid switching between Marshall, CBR, Indirect Tensile (IDT), and SCB test configurations.
• Smart Data Acquisition: Integrated 7″ color touchscreen displays real-time load/deformation curves with automatic peak detection and failure analysis.

Technical Specifications

• Standard Compliance: Supports AASHTO T245 (Marshall), AASHTO T193 (CBR), EN 12697-23 (IDT), and ASTM D6927.
• Maximum Capacity: 50 kN (compression and tension).
• Test Speed: Fully adjustable from 0.01 to 51 mm/min with high-resolution digital control.
• Measurement Precision:
• Load: Class 0.5 (ISO 7500-1) from 1% to 100% of full scale.
• Displacement: 0.001 mm resolution via high-accuracy encoder.
• Connectivity: LAN and USB ports for direct PC control or data transfer to LIMS (Laboratory Information Management Systems).
• Safety Features: Limit switches for crossbeam travel, software-based overload protection, and an emergency stop button.
